Y Strainer (WRAS Approved)
Using the most efficient design for debris removal, utilising generously proportioned
screens, this extends the period before the screen requires cleaning. Available in the sizes 15mm to 22mm with compression ends.
Brass Y-Strainer
Description
Designed for efficient debris removal, this Y-strainer features generously proportioned screens to extend the cleaning interval. Available in sizes 15 mm to 22 mm with compression ends. The body is made of brass with compression ends suitable for copper tubing. The strainer screens are manufactured from 304 austenitic stainless steel for excellent corrosion resistance in potable water and other applications. A nitrile ‘O’-ring seal ensures the cap can be removed and replaced easily for cleaning, making the strainers also suitable for oil service.
Performance
| Applicable Medium | Water, glycol solutions (max 30%) |
|---|---|
| Max Working Pressure | 16 bar (from 2 °C to 30 °C) |
| Working Temperature | Up to 110 °C (intermittent) |
| Strainer Mesh Size | 15 mm: 0.1 mm (100 µm); 22 mm: 0.4 mm (400 µm) |
Materials
| Valve Body | Brass |
|---|---|
| Valve Cap | Brass |
| Screen | Steel (304 stainless) |
| O-Rings | Nitrile Rubber |
| Olive | Copper |
| Compression Nut | Brass |
